ASR-B24DC-START

Active

Altech Corporation

STARTER-KIT SMART RELAY 24VDC IN

Search across all available documentation for this part.

Active

Altech Corporation

STARTER-KIT SMART RELAY 24VDC IN

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	ASR-B24DC-START	ASR-B24 Series

Approval Agency	cULus, CE	cULus, CE
Communications	RS-485	RS-485
Expandable [Max]	3 Racks	3 Racks
Features	Controller, Cable, Software	Controller, Cable, Software
Ingress Protection	IP40	IP40
Mounting Type	DIN Rail	DIN Rail
Number of Inputs and Type [custom]	6	6
Number of Inputs and Type [custom]	2	2
Number of Outputs and Type [custom]	4	4
Number of Outputs and Type [custom]	Relay	Relay
Operating Temperature [Max] [custom]	55 °C	55 °C
Operating Temperature [Min] [custom]	-10 °C	-10 °C
Software	ARS-SOFT	ARS-SOFT
Voltage - Supply [Max]	24 V	24 V
Voltage - Supply [Min]	12 V	12 V

CONTROL LOGIC 6 IN 4 OUT 24V

Part	Communications	Number of Inputs and Type [custom]	Number of Inputs and Type [custom]	Ingress Protection	Voltage - Supply [Max]	Voltage - Supply [Min]	Software	Approval Agency	Number of Outputs and Type [custom]	Number of Outputs and Type [custom]	Operating Temperature [Max] [custom]	Operating Temperature [Min] [custom]	Mounting Type	Expandable [Max]	Features
Altech Corporation ASR-B24DC	RS-485	6	2	IP40	24 V	12 V	ARS-SOFT	CE, cULus	4	Relay	55 °C	-10 °C	DIN Rail	3 Racks
Altech Corporation ASR-B24DC-START	RS-485	6	2	IP40	24 V	12 V	ARS-SOFT	CE, cULus	4	Relay	55 °C	-10 °C	DIN Rail	3 Racks	Cable, Controller, Software

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Programmable Logic Controller (PLC) DIN Rail 12 ~ 24VDC
