Description

General part information

JJN-60V

60A 300 VAC 160 VDC Fuse Cartridge Through Hole

Technical Specifications

Parameters and characteristics for this part

SpecificationJJN-60V
ApplicationsElectrical, Industrial
Approval AgencyCE, UL, CSA
Breaking Capacity (AC)200 kA
Breaking Capacity (DC)20 kA
ClassT
Current Rating60 A
Fuse TypeCartridge
Mounting TypeThrough Hole
Package / CaseRadial
Response TimeFast Blow
Size / Dimension Diameter0.563 in
Size / Dimension Length0.874 in
Voltage Rating - AC300 V
Voltage Rating - DC160 V
