VXN1-1DE-32-44M5450000TR
ActiveMicrochip Technology
1.6X1.2MM CRYSTAL, -40TO+85C, 32
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsVXN1 Data Sheet
VXN1-1DE-32-44M5450000TR
ActiveMicrochip Technology
1.6X1.2MM CRYSTAL, -40TO+85C, 32
Deep-Dive with AI
DocumentsVXN1 Data Sheet
Technical Specifications
Parameters and characteristics for this part
| Specification | VXN1-1DE-32-44M5450000TR |
|---|---|
| ESR (Equivalent Series Resistance) | 80 Ohm |
| Frequency | 44.545 MHz |
| Frequency Stability | 15 ppm |
| Frequency Tolerance | 20 ppm |
| Height - Seated (Max) | 0.45 mm |
| Height - Seated (Max) [Max] [z] | 0.018 " |
| Load Capacitance | 32 pF |
| Mounting Type | Surface Mount |
| Operating Mode | Fundamental |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension [x] | 1.6 mm |
| Size / Dimension [x] | 0.063 in |
| Size / Dimension [y] | 0.047 in |
| Size / Dimension [y] | 1.2 mm |
| Type | MHz Crystal |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Microchip Direct | T/R | 1 | $ 0.74 | |
| 25 | $ 0.62 | |||
| 100 | $ 0.56 | |||
| 1000 | $ 0.54 | |||
| 5000 | $ 0.53 | |||
VXN1 Series
1.6x1.2MM SMD Crystal 4 Pad
| Part | Frequency | Operating Temperature [Max] | Operating Temperature [Min] | Operating Mode | Mounting Type | Height - Seated (Max) | Height - Seated (Max) [Max] [z] | Package / Case | Type | ESR (Equivalent Series Resistance) | Frequency Tolerance | Load Capacitance | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Frequency Stability |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Microchip Technology VXN1-1DE-32-44M5450000TR | 44.545 MHz | 85 °C | -40 °C | Fundamental | Surface Mount | 0.45 mm | 0.018 " | 4-SMD, No Lead | MHz Crystal | 80 Ohm | 20 ppm | 32 pF | 0.047 in | 1.2 mm | 1.6 mm | 0.063 in | 15 ppm |
Description
General part information
VXN1 Series
VXN1 standard crystals come in an industry standard 1.6x1.2mm 4 pad package. The VXN1 has a frequency range of 16MHz to 80MHz with high stability and accuracy.
