TAR212SM
ActiveSensata-Crydom
RELAY REED SPST-NO 500MA 12V
TAR212SM
ActiveSensata-Crydom
RELAY REED SPST-NO 500MA 12V
Description
General part information
TAR212SM
RELAY REED SPST-NO 500MA 12V
Technical Specifications
Parameters and characteristics for this part
| Specification | TAR212SM |
|---|---|
| Coil Current | 0.06 A |
| Coil Resistance | 200 Ohms |
| Coil Type | Non Latching |
| Coil Voltage | 12 VAC |
| Contact Form | SPST-NO |
| Contact Material | Rhodium (Rh), Ruthenium (Ru) |
| Contact Rating (Current) | 500 mA |
| Form A Count | 1 |
| Mounting Type | Through Hole |
| Must Operate Voltage | 8 VDC |
| Must Release Voltage | 2 VDC |
| Operate Time | 1 ms |
| Operating Temperature (Max) | 100 °C |
| Operating Temperature (Min) | -40 °C |
| Release Time | 0.5 ms |
| Switching Voltage AC (Max) | 300 VAC |
| Switching Voltage DC (Max) | 300 VDC |
| Termination Style | PC Pin |
