XCMYK12D

Active

SunLED

LED YELLOW DIFFUSED T-1 3/4 T/H

Search across all available documentation for this part.

Active

SunLED

LED YELLOW DIFFUSED T-1 3/4 T/H

Technical Specifications

Parameters and characteristics for this part

LED YELLOW DIFFUSED T-1 3/4 T/H

Part	Voltage - Forward (Vf) (Typ)	Height (Max) [Max] [z]	Lens Transparency	Lens Style	Package / Case	Supplier Device Package	Wavelength - Dominant	Lens Color	Color	Current - Test	Wavelength - Peak	Millicandela Rating	Viewing Angle	Lens Size	Lens Size	Mounting Type
SunLED XCMYK12D	1.85 V	9.85 mm	Diffused	Round with Domed Top	Radial	T-1 3/4 (5mm)	590 nm	Yellow	Yellow	2 mA	590 nm	69 mcd	30 °	T-1 3/4	5 mm	Through Hole

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Yellow 590nm LED Indication - Discrete 1.85V Radial

Technical documentation and resources
