KR3225Y32768EAW30TAA
ObsoleteKYOCERA AVX
IC RTC CLOCK/CALENDAR I2C SMD
KR3225Y32768EAW30TAA
ObsoleteKYOCERA AVX
IC RTC CLOCK/CALENDAR I2C SMD
Description
General part information
KR3225Y32768EAW30TAA
Real Time Clock (RTC) IC Clock/Calendar I2C, 2-Wire Serial 8-SMD
Technical Specifications
Parameters and characteristics for this part
| Specification | KR3225Y32768EAW30TAA |
|---|---|
| Current - Timekeeping (Max) | 2 µA |
| Date Format | YY-MM-DD-dd |
| Features | Alarm |
| Interface | I2C, 2-Wire Serial |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | 8-SMD |
| Package Name | SMD |
| Time Format | HH:MM:SS |
| Type | Clock/Calendar |
| Voltage - Supply (Maximum) | 5.5 V |
| Voltage - Supply (Minimum) | 1.3 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
No documents available
