Q-0203A0001003i

Active

Amphenol Custom Cable

CBL ASSY BNC-SMA JACK-PLUG 3"

Deep-Dive with AI

Search across all available documentation for this part.

Q-0203A0001003i

Active

Amphenol Custom Cable

CBL ASSY BNC-SMA JACK-PLUG 3"

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	Q-0203A0001003i	Q-0203A0 Series

1st Connector	BNC Jack	BNC Jack
1st Connector Mounting Type	Free Hanging (In-Line)	Free Hanging (In-Line)
1st Contact Gender	Female	Female
2nd Connector	SMA Plug	SMA Plug
2nd Connector Mounting Type	Free Hanging (In-Line)	Free Hanging (In-Line)
2nd Contact Gender	Male	Male
Cable Type	RG-178	RG-178
Color	Copper	Copper
Features	Shielded	Shielded
Frequency - Max [Max]	4 GHz	4 GHz
Length	3 in	3 - 118.1 "
Length	76.2 mm	1 - 1200 mm
Length	-	3.3 - 9.8 ft
Length	-	457.2 mm
Length	-	250 - 457.2 mm
Length	-	9.843 "
Overall Impedance	50 Ohms	50 Ohms
Style	BNC to SMA	BNC to SMA

Q-0203A0 Series

CBL ASSY BNC-SMA JACK-PLUG 9"

Part	Style	1st Connector	Overall Impedance	Color	Frequency - Max [Max]	Cable Type	Length	Length	1st Contact Gender	2nd Connector Mounting Type	2nd Connector	2nd Contact Gender	Features	1st Connector Mounting Type	Length	Length [x]	Length [x]
Amphenol Custom Cable Q-0203A0001009i	BNC to SMA	BNC Jack	50 Ohms	Copper	4 GHz	RG-178	9 "	228.6 mm	Female	Free Hanging (In-Line)	SMA Plug	Male	Shielded	Free Hanging (In-Line)
Amphenol Custom Cable Q-0203A0001060i	BNC to SMA	BNC Jack	50 Ohms	Copper	4 GHz	RG-178	5 '	1.5 m	Female	Free Hanging (In-Line)	SMA Plug	Male	Shielded	Free Hanging (In-Line)	5 ft
Amphenol Custom Cable Q-0203A0001018i	BNC to SMA	BNC Jack	50 Ohms	Copper	4 GHz	RG-178			Female	Free Hanging (In-Line)	SMA Plug	Male	Shielded	Free Hanging (In-Line)		457.2 mm	457.2 mm
Amphenol Custom Cable Q-0203A0001048i	BNC to SMA	BNC Jack	50 Ohms	Copper	4 GHz	RG-178	48 in	1200 mm	Female	Free Hanging (In-Line)	SMA Plug	Male	Shielded	Free Hanging (In-Line)	4 ft
Amphenol Custom Cable Q-0203A0001012i	BNC to SMA	BNC Jack	50 Ohms	Copper	4 GHz	RG-178	12 "	304.8 mm	Female	Free Hanging (In-Line)	SMA Plug	Male	Shielded	Free Hanging (In-Line)
Amphenol Custom Cable Q-0203A00010.5M	BNC to SMA	BNC Jack	50 Ohms	Copper	4 GHz	RG-178	19.69 "	50 cm	Female	Free Hanging (In-Line)	SMA Plug	Male	Shielded	Free Hanging (In-Line)
Amphenol Custom Cable Q-0203A0001036i	BNC to SMA	BNC Jack	50 Ohms	Copper	4 GHz	RG-178	36 in	91.44 cm	Female	Free Hanging (In-Line)	SMA Plug	Male	Shielded	Free Hanging (In-Line)
Amphenol Custom Cable Q-0203A00012.5M	BNC to SMA	BNC Jack	50 Ohms	Copper	4 GHz	RG-178	98.4 in	2.5 m	Female	Free Hanging (In-Line)	SMA Plug	Male	Shielded	Free Hanging (In-Line)	8.2 '
Amphenol Custom Cable Q-0203A0001108i	BNC to SMA	BNC Jack	50 Ohms	Copper	4 GHz	RG-178	108 in	2.7 m	Female	Free Hanging (In-Line)	SMA Plug	Male	Shielded	Free Hanging (In-Line)	9 ft
Amphenol Custom Cable Q-0203A0001006i	BNC to SMA	BNC Jack	50 Ohms	Copper	4 GHz	RG-178	6 in	152.4 mm	Female	Free Hanging (In-Line)	SMA Plug	Male	Shielded	Free Hanging (In-Line)

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	1	$ 71.31
		25	$ 69.91
		50	$ 68.52
		100	$ 67.12
		250	$ 65.73

Description

General part information

Q-0203A0 Series

Cable Assembly Coaxial BNC to SMA RG-178 3.000" (76.20mm)
