CA3292AM96
ActiveON Semiconductor
QUAD-GATED INVERTING POWER DRIVE
CA3292AM96
ActiveON Semiconductor
QUAD-GATED INVERTING POWER DRIVE
Description
General part information
CA3292AM96
Power Switch/Driver 1:1 Bipolar 600mA 28-SOIC
Technical Specifications
Parameters and characteristics for this part
| Specification | CA3292AM96 |
|---|---|
| Current - Output (Max) | 600 mA |
| Fault Protection | Current Limiting (Fixed), Over Temperature, Over Voltage |
| Features | Status Flag, Load Discharge |
| Input Ratio | 1 |
| Input Type | Non-Inverting |
| Interface | On/Off |
| Mounting Type | Surface Mount |
| Number of Outputs | 4 |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Output Configuration | Low Side |
| Output Ratio | 1 |
| Output Type | Bipolar |
| Package Length | 0.295 in |
| Package Name | 28-SOIC |
| Package Width | 7.5 mm |
| Switch Type | Relay, Solenoid Driver |
| Voltage - Load | 15 V |
| Voltage - Supply (Vcc/Vdd) | 7 V |
