Description
General part information
PQA50-D48-S3-DH
Isolated Module DC DC Converter 1 Output 3.3V 10A 36V - 75V Input
Technical Specifications
Parameters and characteristics for this part
| Specification | PQA50-D48-S3-DH |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) | 10 A |
| Efficiency | 91 % |
| Features | OVP, SCP, OTP, Remote On/Off, OCP |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | 6-DIP Module |
| Power (Watts) | 33 W |
| Size / Dimension Height | 0.64 in |
| Size / Dimension Length | 2 in |
| Size / Dimension Width | 1 in |
| Type | Isolated Module |
| Voltage - Input (Max) | 75 V |
| Voltage - Input (Min) | 36 V |
| Voltage - Isolation | 1500 Vrns |
| Voltage - Output 1 | 3.3 V |
