MCPC2425C

MCPC2425C

Active

SOLID STATE RELAYS - INDUSTRIAL MOUNT PM PROP.-CONTROLLER 0-10V IN

MCPC2425C

MCPC2425C

Active

SOLID STATE RELAYS - INDUSTRIAL MOUNT PM PROP.-CONTROLLER 0-10V IN

Description Specifications Series Pricing CAD Documents

Description

General part information

MCPC Series

SOLID STATE RELAYS - INDUSTRIAL MOUNT PM PROP.-CONTROLLER 0-10V IN

Technical Specifications

Parameters and characteristics for this part

Specification	MCPC2425C

Approval Agency	UR, CE
Circuit	SPST-NO (1 Form A)
Load Current	25 A
Mounting Type	Chassis Mount
Operating Temperature (Max)	80 °C
Operating Temperature (Min)	-20 °C
Output Type	Proportional Control, AC
Package / Case	Hockey Puck
Termination Style	Screw Terminal
Voltage - Input (DC) Maximum	10 VDC
Voltage - Input (DC) Minimum	0 V
Voltage - Load (Max)	280 V
Voltage - Load (Min)	180 V

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Sign in to see pricing

Create a free account to access distributor pricing data.

Sign up — free Log in

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

No documents available

MCPC Series

Part	Package / Case	Voltage - Load (Max)	Voltage - Load (Min)	Operating Temperature (Min)	Operating Temperature (Max)	Output Type	Load Current	Approval Agency	Mounting Type	Termination Style	Voltage - Input (Maximum)	Input Current (Maximum)	Input Current (Minimum)	Voltage - Input (Minimum)	Circuit
Sensata-Crydom MCPC4890D	Hockey Puck	530 V	300 V	-20 °C	80 °C	AC Proportional Control	90 A	CE UR	Chassis Mount	Screw Terminal	20 mA	20 mA	4 mA	4 mA	SPST-NO (1 Form A)
