KWS5-5
ObsoleteTDK Corporation
AC/DC CONVERTER 5V 5W
KWS5-5
ObsoleteTDK Corporation
AC/DC CONVERTER 5V 5W
Description
General part information
KWS5-5
Enclosed AC DC Converters 1 Output 5V 1A 85 ~ 265 VAC Input
Technical Specifications
Parameters and characteristics for this part
| Specification | KWS5-5 |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CE, CSA, TUV, UL |
| Current - Output (Max) | 1 A |
| Efficiency | 73 % |
| Features | Universal Input |
| Line Regulation | 0.4 % |
| Load Regulation (Percent) | 0.8 % |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | -10 °C |
| Package / Case | 5-DIP Module |
| Power (Watts) | 5 W |
| Size / Dimension Height | 0.81 in |
| Size / Dimension Length | 2.16 in |
| Size / Dimension Width | 1.77 in |
| Type | Enclosed |
| Voltage - Input (AC) Maximum | 265 VAC |
| Voltage - Input (AC) Minimum | 85 VAC |
| Voltage - Output 1 | 5 V |
| Weight | 0.166 lb |
