MAX98502EVKIT#

Active

Analog Devices Inc./Maxim Integrated

KIT EVAL FOR MAX98502

Search across all available documentation for this part.

Active

Analog Devices Inc./Maxim Integrated

KIT EVAL FOR MAX98502

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	MAX98502EVKIT#	MAX98502 Series

Board Type	Fully Populated	Fully Populated
Features	-	Differential Inputs, Depop, Shutdown
Max Output Power x Channels @ Load	4.1 W, 1	1 - 4.1 W
Mounting Type	-	Surface Mount
Operating Temperature	-	85 °C
Operating Temperature	-	-40 °C
Output Type	1-Channel (Mono)	1-Channel (Mono)
Package / Case	-	16-WFBGA, WLBGA
Supplied Contents	Board(s)	Board(s)
Supplier Device Package	-	16-WLP
Type	-	Class D
Utilized IC / Part	MAX98502	MAX98502
Voltage - Supply [Max]	5.5 V	5.5 V
Voltage - Supply [Min]	2.5 V	2.5 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 81.89

IC AMP CLASS D MONO 4.1W 16WLP

Part	Mounting Type	Voltage - Supply [Min]	Voltage - Supply [Max]	Type	Max Output Power x Channels @ Load	Output Type	Supplier Device Package	Features	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Utilized IC / Part	Supplied Contents	Board Type
Analog Devices Inc./Maxim Integrated MAX98502EWE+T	Surface Mount	2.5 V	5.5 V	Class D	1, 4.1 W	1-Channel (Mono)	16-WLP	Depop, Differential Inputs, Shutdown	85 °C	-40 °C	16-WFBGA, WLBGA
Analog Devices Inc./Maxim Integrated MAX98502EVKIT#		2.5 V	5.5 V		1, 4.1 W	1-Channel (Mono)						MAX98502	Board(s)	Fully Populated

General part information

MAX98502 - 1-Channel (Mono) Output Class D Audio Amplifier Evaluation Board
