Specification	OVSPW1BCR4

Color	White
Current - Max	350 mA
Current - Test	350 mA
Flux (Maximum)	114 lm
Flux (Minimum)	67 lm
Flux (Nominal)	90 lm
Height - Seated (Max)	0.063 in
Lumens/Watt	73 lm/W
Mounting Type	Surface Mount
Package / Case	2828 (7070 Metric)
Package Name	SMD
Size / Dimension Length	0.276 in
Size / Dimension Width	0.236 in
Thermal Resistance of Package	10 °C/W
Viewing Angle	120 °
Voltage - Forward (Vf) (Typ)	3.5 V
