LDD-SMHTA304RISITR

Active

Lumex Opto/Components Inc.

DISPLAY 7-SEG 0.3" DBL RED 20SMD

Deep-Dive with AI

Search across all available documentation for this part.

LDD-SMHTA304RISITR

Active

Lumex Opto/Components Inc.

DISPLAY 7-SEG 0.3" DBL RED 20SMD

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	LDD-SMHTA304RISITR

Color	Red
Common Pin	Common Anode
Current - Test	20 mA
Digit/Alpha Size	0.3 in
Digit/Alpha Size	7.62 mm
Display Type	7-Segment
Millicandela Rating	4.5 mcd
Number of Characters	2
Package / Case	20-SMD, No Lead
Size / Dimension [x]	0.394 "
Size / Dimension [x]	10 mm
Size / Dimension [y]	0.583 in
Size / Dimension [y]	14.8 mm
Size / Dimension [z]	0.157 "
Size / Dimension [z]	4 mm
Voltage - Forward (Vf) (Typ)	2 V
Wavelength - Peak [custom]	640 nm

LDD-SMHTA304 Series

DISPLAY 7-SEG 0.3" DBL RED 20SMD

Part	Wavelength - Peak [custom]	Common Pin	Voltage - Forward (Vf) (Typ)	Display Type	Package / Case	Color	Digit/Alpha Size	Digit/Alpha Size	Millicandela Rating	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Number of Characters	Current - Test
Lumex Opto/Components Inc. LDD-SMHTA304RISITR	640 nm	Common Anode	2 V	7-Segment	20-SMD, No Lead	Red	0.3 in	7.62 mm	4.5 mcd	0.583 in	0.157 "	0.394 "	14.8 mm	10 mm	4 mm	2	20 mA

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Cut Tape (CT)	1	$ 2.50
		10	$ 1.77
		100	$ 1.48
	Digi-Reel®	1	$ 2.50
		10	$ 1.77
		100	$ 1.48
	Tape & Reel (TR)	600	$ 1.48

Description

General part information

LDD-SMHTA304 Series

Display Modules - LED Character and Numeric Red 7-Segment 2 Character Common Anode 2V 20mA 0.394" H x 0.583" W x 0.157" D (10.00mm x 14.80mm x 4.00mm) 20-SMD, No Lead
