LC1K09004M7
ActiveSCHNEIDER ELECTRIC
CONTACTOR, 9 A, DIN RAIL, PANEL, 600 VAC, 4PST-NO, 4 POLE, 3 HP
LC1K09004M7
ActiveSCHNEIDER ELECTRIC
CONTACTOR, 9 A, DIN RAIL, PANEL, 600 VAC, 4PST-NO, 4 POLE, 3 HP
Description
General part information
LC1K09004M7
CONTACTOR, 9 A, DIN RAIL, PANEL, 600 VAC, 4PST-NO, 4 POLE, 3 HP
Technical Specifications
Parameters and characteristics for this part
| Specification | LC1K09004M7 |
|---|---|
| Coil Voltage (Max) | 230 VAC/DC |
| Coil Voltage (Min) | 220 VAC |
| Contact Form | 4 Form A, PST-NO |
| Contact Rating (Current) | 20 A |
| Mounting Type | Chassis Mount |
| Operate Time | 20 ms |
| Pin Count | 4 |
| Release Time | 20 ms |
| Switching Voltage AC (Max) | 690 VAC |
| Termination Style | Screw Terminal |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
