704.002.5A
ActiveEAO
INDICATOR PANEL LED
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
704.002.5A
ActiveEAO
INDICATOR PANEL LED
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | 704.002.5A | 704.002 Series |
|---|---|---|
| Features | - | Flashing LED |
| Ingress Protection | IP65 | IP65 |
| Lamp Color | - | Red |
| Lens Color | Green | Colorless, Green, Yellow, Red |
| Lens Size [diameter] | 29 mm | 29 mm |
| Lens Transparency | Clear | Clear |
| Panel Cutout Dimensions | 0.88 in | 0.88 in |
| Panel Cutout Dimensions | 22.3 mm | 22.3 mm |
| Panel Cutout Shape | Round | Round |
| Termination Style | Screw Terminal | Screw Terminal |
| Type | LED | LED |
704.002 Series
INDICATOR PANEL LED CLR
| Part | Panel Cutout Shape | Lens Color | Panel Cutout Dimensions | Panel Cutout Dimensions | Features | Lens Size [diameter] | Termination Style | Ingress Protection | Type | Lens Transparency | Lamp Color |
|---|---|---|---|---|---|---|---|---|---|---|---|
EAO 704.002.7 | Round | Colorless | 0.88 in | 22.3 mm | Flashing LED | 29 mm | Screw Terminal | IP65 | LED | Clear | |
EAO 704.002.5 | Round | Green | 0.88 in | 22.3 mm | Flashing LED | 29 mm | Screw Terminal | IP65 | LED | Clear | |
EAO 704.002.4 | Round | Yellow | 0.88 in | 22.3 mm | Flashing LED | 29 mm | Screw Terminal | IP65 | LED | Clear | |
EAO 704.002.2A | Round | 0.88 in | 22.3 mm | 29 mm | Screw Terminal | IP65 | LED | Clear | Red | ||
EAO 704.002.2 | Round | Red | 0.88 in | 22.3 mm | 29 mm | Screw Terminal | IP65 | LED | Clear | ||
EAO 704.002.5A | Round | Green | 0.88 in | 22.3 mm | 29 mm | Screw Terminal | IP65 | LED | Clear |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 27.52 | |
| 10 | $ 22.85 | |||
Description
General part information
704.002 Series
LED Panel Indicator Clear Screw Terminal
