000-46650-75

Active

AMPHENOL RF

CONN TERMINATOR PLUG BNC 75OHM

Search across all available documentation for this part.

Active

AMPHENOL RF

CONN TERMINATOR PLUG BNC 75OHM

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	000-46650-75	000-46 Series

Body Finish	Nickel	Nickel
Body Material	Brass	Brass
Connector Style	BNC	BNC
Connector Type	Male Pin, Plug	Male Pin, Plug
Contact Finish	Gold	Gold
Contact Material	Brass	Brass
Dielectric Material	Polytetrafluoroethylene (PTFE)	Polytetrafluoroethylene (PTFE)
Impedance	75 Ohms	50 - 75 Ohms
Mounting Type	Free Hanging, Cap	Free Hanging, Cap

CONN TERMINATOR PLUG BNC 50OHM

Part	Connector Style	Impedance	Body Finish	Contact Finish	Connector Type	Mounting Type	Contact Material	Dielectric Material	Body Material
AMPHENOL RF 000-46650-51RFX	BNC	50 Ohms	Nickel	Gold	Male Pin, Plug	Cap, Free Hanging
AMPHENOL RF 000-46650-75	BNC	75 Ohms	Nickel	Gold	Male Pin, Plug	Cap, Free Hanging	Brass	Polytetrafluoroethylene (PTFE)	Brass

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	100	$ 13.40

General part information

Terminator Coax Connector Plug, Male Pin BNC 75 Ohms

Technical documentation and resources

No documents available
