CMA02040X1801GB300
ActiveVishay Dale
RES SMD 1.8K OHM 2% 0.4W 0204
CMA02040X1801GB300
ActiveVishay Dale
RES SMD 1.8K OHM 2% 0.4W 0204
Description
General part information
CMA02040X1801GB300
1.8 kOhms ±2% 0.4W, 2/5W Chip Resistor MELF, 0204 Automotive AEC-Q200, Pulse Withstanding Carbon Film
Technical Specifications
Parameters and characteristics for this part
| Specification | CMA02040X1801GB300 |
|---|---|
| Composition | Carbon Film |
| Features | Pulse Withstanding, Automotive AEC-Q200 |
| Number of Terminations | 2 |
| Operating Temperature (Max) | 155 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 0204, MELF |
| Package Name | 0204 |
| Power (Watts) | 0.4 W |
| Power (Watts) Options | 2/5W |
| Ratings | AEC-Q200 |
| Resistance | 1.8 kOhm |
| Size / Dimension Diameter | 0.055 in |
| Size / Dimension Length | 0.142 in |
| Tolerance | 2 % |
