PCXA603-1R2M
ActiveAllied Components International
1.2UH +/-20% HI-CURR. PWR. CHOKE
PCXA603-1R2M
ActiveAllied Components International
1.2UH +/-20% HI-CURR. PWR. CHOKE
Description
General part information
PCXA603-1R2M
1.2 µH Shielded Inductor 16 A 7.4mOhm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | PCXA603-1R2M |
|---|---|
| Current - Saturation (Isat) | 16 A |
| Current Rating | 16 A |
| DC Resistance (DCR) (Max) | 7.4 mOhm |
| Height - Seated (Max) | 0.118 in |
| Inductance | 1.2 µH |
| Inductance Frequency - Test | 100 kHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Shielding | Shielded |
| Size / Dimension Length | 0.26 in |
| Size / Dimension Width | 0.252 in |
| Tolerance | 20 % |
