SH3000-160-160-0.35
ActiveShiu Li Technology Co., Ltd.
HIGH INSULATED THERMAL PAD WITH
SH3000-160-160-0.35
ActiveShiu Li Technology Co., Ltd.
HIGH INSULATED THERMAL PAD WITH
Description
General part information
SH3000-160-160-0.35
Thermal Pad Green 160.00mm x 160.00mm Square
Technical Specifications
Parameters and characteristics for this part
| Specification | SH3000-160-160-0.35 |
|---|---|
| Backing | Fiberglass |
| Carrier | Fiberglass |
| Color | Green |
| Material | Silicone |
| Outline Length | 160 mm |
| Outline Width | 160 mm |
| Shape | Square |
| Shelf Life | 120 Months |
| Shelf Life Start | Date of Shipment |
| Storage/Refrigeration Temperature | Room Temperature |
| Thermal Conductivity | 2 W/m-K |
| Thickness | 0.0138 in |
| Type | Conductive Insulator Pad |
