LWS-0512H
ActiveDiwell Electronics
DC DC CONVERTER 12V 5W
LWS-0512H
ActiveDiwell Electronics
DC DC CONVERTER 12V 5W
Description
General part information
LWS-0512H
Isolated Module DC DC Converter 1 Output 12V 417mA 4.5V - 9V Input
Technical Specifications
Parameters and characteristics for this part
| Specification | LWS-0512H |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | FCC, CE |
| Current - Output (Max) | 417 mA |
| Efficiency | 70 % |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 71 °C |
| Operating Temperature (Min) | -25 °C |
| Package Leads | 4 Leads |
| Package Name | 5-DIP Module |
| Power (Watts) | 5 W |
| Size / Dimension Height | 0.44 in |
| Size / Dimension Length | 2 in |
| Size / Dimension Width | 1 in |
| Type | Isolated Module |
| Voltage - Input (Max) | 9 V |
| Voltage - Input (Min) | 4.5 V |
| Voltage - Isolation | 1500 Vrns |
| Voltage - Output 1 | 12 V |
