10534CS
ActiveCentury Spring Corp
COMP O= .328,L= 1.41,W= .031
10534CS
ActiveCentury Spring Corp
COMP O= .328,L= 1.41,W= .031
Description
General part information
10534CS
COMP O= .328,L= 1.41,W= .031
Technical Specifications
Parameters and characteristics for this part
| Specification | 10534CS |
|---|---|
| Diameter - Inside | 0.266 in |
| Diameter - Outside | 0.328 in |
| End Style | Closed |
| Finish | Zinc |
| Free Length | 1.41 in |
| Material | Music Wire |
| Rate (lbs/in) | 3.7 lbs/in |
| Type | Compression |
| Wire Diameter | 0.031 in |
