AM1D-0309DZ

Active

aimtec

DC DC CONVERTER +/-9V 1W

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

AM1D-0309DZ

Active

aimtec

DC DC CONVERTER +/-9V 1W

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	1	$ 3.80
		5	$ 3.72
		10	$ 3.65
		20	$ 3.57
		40	$ 3.50
		60	$ 3.43
		80	$ 3.36
		100	$ 3.30
		120	$ 3.23

Description

General part information

AM1D Series

Isolated Module DC DC Converter 2 Output -9 ~ 9V -9V 56mA, 56mA 2.97V - 3.63V Input

Documents

Technical documentation and resources

Datasheet

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	AM1D-0309DZ	AM1D Series

Applications	ITE (Commercial)	ITE (Commercial)
Approval Agency	CE, cURus, cULus	CE, cURus, cULus, IEC, UL, EN, CE, cURus
Current - Output (Max)	-	21 - 303 mA
Current - Output (Max)	-	20 - 152 mA
Current - Output (Max)	-	42 mA
Current - Output (Max)	-	20 - 152 mA
Current - Output (Max)	-	21 mA
Current - Output (Max)	-	41 mA
Efficiency	75 %	66 - 89 %
Mounting Type	Through Hole	Through Hole
Number of Outputs	2	1 - 2
Operating Temperature [Max]	85 °C	85 °C
Operating Temperature [Min]	-40 °C	-40 °C
Package / Case	-	7-SIP Module, 4 Leads, 7-SIP Module, 5 Leads, 7-SIP Module, 6 Leads
Power (Watts)	-	0.99 - 999 mW
Size / Dimension	-	0.76 "
Size / Dimension	-	0.37 - 0.39 in
Size / Dimension	-	0.24 "
Size / Dimension [x]	19.5 mm	19.5 mm
Size / Dimension [x]	0.77 "	0.77 - 19.5 mm
Size / Dimension [y]	6 mm	6 mm
Size / Dimension [y]	0.24 in	0.24 - 6 mm
Size / Dimension [z]	0.39 in	0.39 - 10 mm
Size / Dimension [z]	10 mm	10 mm
Standard Number	-	62368-1
Supplier Device Package	-	7-SIP
Type	Isolated Module	Isolated Module
Voltage - Input (Max) [Max]	3.63 V	3.63 - 52.8 V
Voltage - Input (Min) [Min]	2.97 V	2.97 - 43.6 V
Voltage - Isolation	1000 V	5.2 - 6000 kV
Voltage - Output 1	-	3.3 - 24 V
Voltage - Output 1	-	3.3 - 24 V
Voltage - Output 1	-	-24 - -3.3 V
Voltage - Output 2	-9 V	-24 - 24 V

AM1D Series

DC DC CONVERTER 5V 1W

...

Part	Voltage - Isolation	Number of Outputs	Voltage - Input (Min) [Min]	Applications	Type	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Efficiency	Voltage - Input (Max) [Max]	Approval Agency	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Voltage - Output 1	Current - Output (Max) [Max]	Current - Output (Max)	Voltage - Output 2	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Power (Watts)	Current - Output (Max) [Max]	Standard Number	Voltage - Output 1 [Max]	Voltage - Output 1 [Min]	Current - Output (Max)
aimtec AM1D-0305SH52Z	5.2 kV	1	2.97 V	ITE (Commercial)	Isolated Module	Through Hole	85 °C	-40 °C	78 %	3.63 V	CE, cULus, cURus	0.76 "	0.39 in	10 mm	19.5 mm	6 mm	0.24 "	5 V	200 mA
aimtec AM1D-241818DZ	1000 V	2	21.6 V	ITE (Commercial)	Isolated Module	Through Hole	85 °C	-40 °C	78 %	26.4 V	CE, cULus, cURus	0.76 "	0.39 in	10 mm	19.5 mm	6 mm	0.24 "	18 V		27 mA	18 V
aimtec AM1D-0512SH30Z	3000 V	1	4.5 V	ITE (Commercial)	Isolated Module	Through Hole	85 °C	-40 °C	79 %	5.5 V	CE, cULus, cURus			0.39 in	0.77 "	0.24 in		12 V	83 mA			6 mm	10 mm	19.5 mm	1 mW
aimtec AM1D-1518SH40Z	4000 V	1	13.5 V	ITE (Commercial)	Isolated Module	Through Hole	85 °C	-40 °C	80 %	16.5 V	CE, cULus, cURus	0.76 "	0.39 in	10 mm	19.5 mm	6 mm	0.24 "	18 V	56 mA
aimtec AM1D-1518SH60Z	6000 V	1	13.5 V	ITE (Commercial)	Isolated Module	Through Hole	85 °C	-40 °C	80 %	16.5 V	CE, cULus, cURus	0.76 "	0.39 in	10 mm	19.5 mm	6 mm	0.24 "	18 V	56 mA
aimtec AM1D-2412DZ	1000 V	2	21.6 V	ITE (Commercial)	Isolated Module	Through Hole	85 °C	-40 °C	80 %	26.4 V	CE, cURus, EN, IEC, UL	0.76 "	0.39 in	10 mm	19.5 mm	6 mm	0.24 "	12 V	42 mA		-12 V					42 mA	62368-1
aimtec AM1D-1515DH40Z	4000 V	2	13.5 V	ITE (Commercial)	Isolated Module	Through Hole	85 °C	-40 °C	77 %	16.5 V	CE, cULus, cURus	0.76 "	0.39 in	10 mm	19.5 mm	6 mm	0.24 "			33 mA	-15 V							15 V	-15 V
aimtec AM1D-1215SH40Z	4000 V	1	10.8 V	ITE (Commercial)	Isolated Module	Through Hole	85 °C	-40 °C		13.2 V	CE, cULus, cURus	0.76 "	0.39 in	10 mm	19.5 mm	6 mm	0.24 "	15 V	67 mA
aimtec AM1D-1512DH60Z	6000 V	2	13.5 V	ITE (Commercial)	Isolated Module	Through Hole	85 °C	-40 °C	77 %	16.5 V	CE, cURus, EN, IEC, UL	0.76 "	0.39 in	10 mm	19.5 mm	6 mm	0.24 "	12 V	42 mA		-12 V					42 mA	62368-1
aimtec AM1D-240505DZ	1000 V	2	21.6 V	ITE (Commercial)	Isolated Module	Through Hole	85 °C	-40 °C	75 %	26.4 V	CE, cULus, cURus			0.39 in	0.77 "	0.24 in		5 V		100 mA	5 V	6 mm	10 mm	19.5 mm						100 mA
