22UL3173STRRED25

22UL3173STRRED25

Active
Remington Industries

#22 UL3173 600V WIRE RED 25'

Find alt
22UL3173STRRED25

22UL3173STRRED25

Active
Remington Industries

#22 UL3173 600V WIRE RED 25'

Find alt

Description

General part information

22UL3173STRRED25

22 AWG Hook-Up Wire 7/30 Red 600V 25.00' (7.62m)

Technical Specifications

Parameters and characteristics for this part

Specification22UL3173STRRED25
Cable TypeHook-Up
Conductor MaterialTinned, Copper
Conductor Strand Count7 Strands
Conductor Strand Gauge30
FeaturesCorrosion Resistant, Oil Resistant, Abrasion Resistant, Chemical Resistant, Solvent Resistant
Jacket (Insulation) Diameter0.09 in
Jacket (Insulation) MaterialPolyethylene (XLPE)
Jacket (Insulation) Thickness0.03 in
Jacket ColorRed
Length25 ft
Operating Temperature125 °C
Ratings3173, Style, UL
Voltage600 V
Wire Gauge22 AWG
