Description
General part information
CO22H4-33.3333-18JDTSTK
33.3333 MHz XO (Standard) CMOS Oscillator 1.8V Enable/Disable 4-SMD, No Lead
Technical Specifications
Parameters and characteristics for this part
| Specification | CO22H4-33.3333-18JDTSTK |
|---|---|
| Base Resonator | Crystal |
| Current - Supply (Max) | 10 mA, 7 mA |
| Frequency | 33.3333 MHz |
| Frequency Stability | 20 ppm, 30 ppm |
| Function | Enable, Disable |
| Height - Seated (Max) | 0.022 in, 0.039 in |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Output | HCMOS, CMOS |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension Length | 0.098 in |
| Size / Dimension Width | 0.079 in |
| Type | XO (Standard) |
| Voltage - Supply | 1.8 V |
