AVEK227M16F24T-F
ObsoleteCornell Dubilier Knowles
CAP ALUM 220UF 20% 16V SMD
AVEK227M16F24T-F
ObsoleteCornell Dubilier Knowles
CAP ALUM 220UF 20% 16V SMD
Description
General part information
AVEK227M16F24T-F
220 µF 16 V Aluminum Electrolytic Capacitors Radial, Can - SMD 1.7Ohm @ 120Hz 5000 Hrs @ 105°C
Technical Specifications
Parameters and characteristics for this part
| Specification | AVEK227M16F24T-F |
|---|---|
| Applications | General Purpose |
| Capacitance | 220 µF |
| ESR (Equivalent Series Resistance) | 1.7 Ohm |
| Height - Seated (Max) | 0.394 in |
| Lifetime | 5000 Hrs |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Radial, Can - SMD |
| Polarization | Polar |
| Ripple Current | 222.5 mA, 178 mA |
| Size / Dimension Diameter | 0.315 in |
| Surface Mount Land Length | 0.331 in |
| Surface Mount Land Width | 0.331 in |
| Tolerance | 20 % |
| Voltage - Rated | 16 V |
