MI316MTPA2
ActiveKanebridge
MACH SCREW PAN 6-LOBE M3X0.5
MI316MTPA2
ActiveKanebridge
MACH SCREW PAN 6-LOBE M3X0.5
Description
General part information
MI316MTPA2
M3x0.5 Pan Head Machine Screw 6-Lobe Drive Stainless Steel
Technical Specifications
Parameters and characteristics for this part
| Specification | MI316MTPA2 |
|---|---|
| Drive Type | 6-Lobe |
| Features | Standard |
| Head Diameter | 0.215 in |
| Head Height | 0.092 in |
| Length - Below Head | 0.63 in |
| Length - Overall | 0.722 in |
| Material | Stainless Steel |
| Plating | Plain |
| Screw Head Type | Pan Head |
| Thread Diameter | 3 mm |
| Thread Pitch | 0.5 mm |
| Type | Machine Screw |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
No documents available
