B82141A1393K009
ActiveEPCOS - TDK Electronics
FIXED IND 39UH 285MA 1.21 OHM TH
B82141A1393K009
ActiveEPCOS - TDK Electronics
FIXED IND 39UH 285MA 1.21 OHM TH
Description
General part information
B82141A1393K009
39 µH Unshielded Drum Core, Wirewound Inductor 285 mA 1.21Ohm Max Axial
Technical Specifications
Parameters and characteristics for this part
| Specification | B82141A1393K009 |
|---|---|
| Current Rating | 285 mA |
| DC Resistance (DCR) (Max) | 1.21 Ohm |
| Frequency - Self Resonant | 8.5 MHz |
| Inductance | 39 µH |
| Inductance Frequency - Test | 2.52 MHz |
| Material - Core | Ferrite |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Axial |
| Q | 55 |
| Shielding | Unshielded |
| Size / Dimension Diameter | 0.118 in |
| Size / Dimension Length | 0.268 in |
| Tolerance | 10 % |
| Type | Drum Core, Wirewound |
