Description
General part information
PSAN-1CV-NPT1/8
Pressure Sensor 145.04PSI (1000kPa) Male - 1/8" (3.18mm) NPT 1 V ~ 5 V Module Box with Display
Technical Specifications
Parameters and characteristics for this part
| Specification | PSAN-1CV-NPT1/8 |
|---|---|
| Accuracy | 1 % |
| Maximum Pressure | 217.56 PSI |
| Operating Pressure | 145.04 PSI |
| Operating Temperature (Max) | 50 °C |
| Operating Temperature (Min) | -10 °C |
| Output Type | Analog Voltage, NPN - Open Collector |
| Output Voltage (Max) | 5 V |
| Output Voltage (Min) | 1 V |
| Package / Case | Module Box with Display |
| Port Diameter | 0.125 " |
| Port Feature | NPT |
| Port Gender | Male |
| Port Style | Threaded |
| Termination Style | Connector |
| Voltage - Supply (Maximum) | 24 VAC |
| Voltage - Supply (Minimum) | 12 VDC |
