Description
General part information
SFC-A322-23-L
Machine Safety Controller General Purpose 24VDC Supply DIN Rail
Technical Specifications
Parameters and characteristics for this part
| Specification | SFC-A322-23-L |
|---|---|
| {base_key} (Max) | 3 sec |
| {base_key} (Min) | 0 |
| Approval Agency | TUV, S-Mark, EAC, CE, cULus |
| Auxiliary Output Count | 2 |
| Auxiliary Output Type | Solid State |
| Controller Type | General Purpose |
| Delay Time (Max) | 3 sec |
| Delay Time (Min) | 0 sec |
| Features | Delay Time 0 ~ 3sec |
| Ingress Protection | IP20 |
| Input Types | Digital |
| Mounting Type | DIN Rail |
| Number of Inputs | 20 |
| Operating Temperature (Max) | 55 °C |
| Operating Temperature (Min) | -10 °C |
| Safety Category | PLe, Category 4, SIL3 |
| Safety Output Type | Relay |
| Safety Outputs (Count) | 5 count |
| Termination Style | Spring Terminal |
| Voltage - Supply | 24 VDC |
| Weight | 0.309 lb |
