Specification	9472LESQ-12(6)

Adhesive	Acrylic
Backing	Polycoated Kraft Liner
Carrier	Polycoated Kraft Liner
Length	12 in
Shelf Life	24 Months
Shelf Life Start	Date of Shipment
Storage/Refrigeration Temperature	70 °F
Tape Type	Adhesive Transfer
Thickness - Adhesive	0.0052 in
Thickness - Backing, Carrier	0.0042 in
Usage	General Purpose
Width	12 in

9472LE Series

...

Part	Shelf Life Start	Shelf Life	Storage/Refrigeration Temperature	Usage	Thickness	Length	Thickness - Backing, Carrier	Tape Type	Color	Temperature Range (Max)	Temperature Range (Min)	Width	Carrier	Backing	Thickness - Adhesive	Adhesive	Length (ft)	Length (yd)
3M (TC) 3M 9472LE 0.5" X 0.75"-250	Date of Manufacture	18 Months	70 °F	Bonding	0.0094 in	0.75 in	0.0042 in	Adhesive Transfer	Clear	300 °F	-40 °F	12.7 mm	Polycoated Kraft Liner	Polycoated Kraft Liner	0.0052 in	300LSE Acrylic Acrylic 300LSE
3M (TC) 9472LE-1.5-1.25(100)	Date of Manufacture	18 Months	70 °F	Bonding	0.0094 in	1.25 in	0.0042 in	Adhesive Transfer	Clear	300 °F	-40 °F	1.5 in	Polycoated Kraft Liner	Polycoated Kraft Liner	0.0052 in	300LSE Acrylic Acrylic 300LSE
3M (TC) 3M 9472LE 0.75"SQ-250	Date of Manufacture	18 Months	70 °F	Bonding	0.0094 in	0.75 in	0.0042 in	Adhesive Transfer	Clear	300 °F	-40 °F	0.75 in	Polycoated Kraft Liner	Polycoated Kraft Liner	0.0052 in	300LSE Acrylic Acrylic 300LSE
3M (TC) 3M 9472LE 4" X 8.625"-25	Date of Manufacture	18 Months	70 °F	Bonding	0.0094 in	8.63 in	0.0042 in	Adhesive Transfer	Clear	300 °F	-40 °F	4 in	Polycoated Kraft Liner	Polycoated Kraft Liner	0.0052 in	300LSE Acrylic Acrylic 300LSE
3M (TC) 3M 9472LE 0.71" X 60YD	Date of Manufacture	18 Months	70 °F	Bonding	0.0094 in		0.0042 in	Adhesive Transfer	Clear	300 °F	-40 °F	0.71 in	Polycoated Kraft Liner	Polycoated Kraft Liner	0.0052 in	300LSE Acrylic Acrylic 300LSE	180 ft	60 yd
3M (TC) 5-9472LE-1	Date of Shipment	24 Months	70 °F	General Purpose		25.4 mm	0.0042 in	Adhesive Transfer				1 in	Polycoated Kraft Liner	Polycoated Kraft Liner	0.0052 in	Acrylic
3M (TC) 9472LE-0.25-60	Date of Manufacture	18 Months	70 °F	Bonding	0.0094 in		0.0042 in	Adhesive Transfer	Clear	300 °F	-40 °F	0.25 in	Polycoated Kraft Liner	Polycoated Kraft Liner	0.0052 in	300LSE Acrylic Acrylic 300LSE	180 ft	60 yd
3M (TC) 3M 9472LE 2" X 8.625"-25	Date of Manufacture	18 Months	70 °F	Bonding	0.0094 in	8.63 in	0.0042 in	Adhesive Transfer	Clear	300 °F	-40 °F	2 in	Polycoated Kraft Liner	Polycoated Kraft Liner	0.0052 in	300LSE Acrylic Acrylic 300LSE
3M (TC) 9472LE-0.75-60	Date of Manufacture	18 Months	70 °F	Bonding	0.0094 in		0.0042 in	Adhesive Transfer	Clear	300 °F	-40 °F	0.75 in	Polycoated Kraft Liner	Polycoated Kraft Liner	0.0052 in	300LSE Acrylic Acrylic 300LSE	180 ft	60 yd
3M (TC) 3M 9472LE 4" X 7.25"-25	Date of Manufacture	18 Months	70 °F	Bonding	0.0094 in	7.25 in	0.0042 in	Adhesive Transfer	Clear	300 °F	-40 °F	4 in	Polycoated Kraft Liner	Polycoated Kraft Liner	0.0052 in	300LSE Acrylic Acrylic 300LSE
