Specification	PJA1000F-36

Applications	ITE (Commercial)
Approval Agency	CE, DEMKO, cURus
Current - Output 1	28 A
Efficiency	88 %
Features	PFC, Adjustable Output, Universal Input
Mounting Type	Chassis Mount
Number of Outputs	1
Operating Temperature (Max)	70 °C
Operating Temperature (Min)	-20 °C
Power (Watts)	1.008 kW
Size / Dimension Height	2.4 in
Size / Dimension Length	9.45 in
Size / Dimension Width	5.91 in
Type	Enclosed
Voltage - Input (AC) Maximum	264 V
Voltage - Input (AC) Minimum	85 VAC
Voltage - Isolation	3 kV
Voltage - Output 1	36 V

PJA Series

...

Part	Current - Output 1	Efficiency	Applications	Voltage - Isolation	Type	Voltage - Input (AC) Minimum	Voltage - Input (AC) Maximum	Number of Outputs	Operating Temperature (Max)	Operating Temperature (Min)	Voltage - Output 1	Features	Approval Agency	Power (Watts)	Mounting Type	Size / Dimension Height	Size / Dimension Width	Size / Dimension Length	Standard Number	Minimum Load Required	AC Voltage - Input (Max)	AC Voltage - Input (Min)	Current - Output (Max)	Input Type
Cosel USA, Inc. PJA1500F-24-V	64 A	88 %	ITE (Commercial)	3 kV	Enclosed	85 VAC	264 V	1	70 °C	-20 °C	24 V	Adjustable Output PFC Universal Input	CE cURus DEMKO	1.536 kW	Chassis Mount	2.4 in	7.01 in	10.55 in
Cosel USA, Inc. PJA1500F-12-R	125 A	85 %	ITE (Commercial)	3 kV	Enclosed	85 VAC	264 V	1	70 °C	-20 °C	12 V	Adjustable Output PFC Remote On/Off Universal Input	CE cURus DEMKO	1.5 kW	Chassis Mount	2.4 in	7.01 in	10.55 in
Cosel USA, Inc. PJA1000F-48	21 A	88 %	ITE (Commercial)	3 kV	Enclosed	85 VAC	264 V	1	70 °C	-20 °C	48 V	Universal Input	CE CSA cURus DEMKO UL	1 kW	Chassis Mount	2.4 in	5.91 in	9.45 in	508 60950-1 62368-1
Cosel USA, Inc. PJA1000F-12-R	84 A	85 %	ITE (Commercial)	3 kV	Enclosed	85 VAC	264 V	1	70 °C	-20 °C	12 V	Adjustable Output PFC Remote On/Off Universal Input	CE cURus DEMKO	1.008 kW	Chassis Mount	2.4 in	5.91 in	9.45 in
Cosel USA, Inc. PJA1000F-12-G	84 A	85 %	ITE (Commercial)	3 kV	Enclosed	85 VAC	264 V	1	70 °C	-20 °C	12 V	Adjustable Output PFC Universal Input	CE cURus DEMKO	1.008 kW	Chassis Mount	2.4 in	5.91 in	9.45 in
Cosel USA, Inc. PJA150F-15-R	10 A	87 %	ITE (Commercial)	3 kV	Enclosed	85 VAC	264 V	1	70 °C	-20 °C	15 V	Remote On/Off Universal Input	CE CSA cURus DEMKO UL	150 W	Chassis Mount	3.82 in	1.61 in	5.08 in	508 60950-1 62368-1	No
Cosel USA, Inc. PJA1500F-24-W	64 A	88 %	ITE (Commercial)	3 kV	Enclosed	85 VAC	264 V	1	70 °C	-20 °C	24 V	Adjustable Output PFC Remote Sense Universal Input	CE cURus DEMKO	1.536 kW	Chassis Mount	2.4 in	7.01 in	10.55 in
Cosel USA, Inc. PJA100F-24-N2		88 %	ITE (Commercial)	3 kV				1	70 °C	-20 °C	24 V	Universal Input	CE CSA cURus DEMKO UL	103 W		3.82 in	1.61 in	4.29 in	508 60950-1 62368-1	No	264 VAC	85 VAC	4.3 A	AC
Cosel USA, Inc. PJA1000F-48-R	21 A	88 %	ITE (Commercial)	3 kV	Enclosed	85 VAC	264 V	1	70 °C	-20 °C	48 V	Adjustable Output PFC Remote On/Off Universal Input	CE cURus DEMKO	1.008 kW	Chassis Mount	2.4 in	5.91 in	9.45 in
Cosel USA, Inc. PJA1500F-36-G	42 A	88 %	ITE (Commercial)	3 kV	Enclosed	85 VAC	264 V	1	70 °C	-20 °C	36 V	Adjustable Output PFC Universal Input	CE cURus DEMKO	1512 W	Chassis Mount	2.4 in	7.01 in	10.55 in
