ARK-2251-S3A1U
ActiveAdvantech Corporation
INTEL RAPTER LAKE I5 1335UE 1.3G
ARK-2251-S3A1U
ActiveAdvantech Corporation
INTEL RAPTER LAKE I5 1335UE 1.3G
Description
General part information
ARK-2251-S3A1U
INTEL RAPTER LAKE I5 1335UE 1.3G
Technical Specifications
Parameters and characteristics for this part
| Specification | ARK-2251-S3A1U |
|---|---|
| Approval Agency | CCC, cULus, CE, FCC, UL, BSMI, CB |
| Core Processor | Intel® Core™ i5-1335UE |
| Core Processor Frequency | 1.3 GHz |
| Display Type | No Display |
| Expansion Type | mini PCIe, M.2 |
| Memory Max Capacity | 64 GB |
| Memory Type | DDR5 SODIMM |
| Mounting Type | Wall Mount |
| Operating System | Windows 10, Linux |
| Operating Temperature (Max) | 60 °C |
| Operating Temperature (Min) | -20 °C |
| Storage Type | mSATA |
| Type | Box PC |
| Voltage - Supply (Maximum) | 24 VAC |
| Voltage - Supply (Minimum) | 12 VDC |
