Specification	B43601A9277M000

Applications	General Purpose
Capacitance	270 µF
ESR (Equivalent Series Resistance)	400 mOhm
Height - Seated (Max)	1.85 in
Impedance	550 mOhms
Lead Spacing	0.394 in
Lifetime	10000 Hrs
Mounting Type	Through Hole
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	-40 °C
Package / Case	Can - Snap-In, Radial
Polarization	Polar
Ripple Current	1.61 A
Size / Dimension Diameter	0.866 in
Tolerance	20 %
Voltage - Rated	400 V
