Specification	B32529C1683K000

Applications	EMI, Automotive, RFI Suppression
Capacitance	0.068 µF
Dielectric Material	Metallized - Stacked, Polyester, Polyethylene Terephthalate (PET)
Height - Seated (Max)	0.256 in
Lead Spacing	0.197 in
Mounting Type	Through Hole
Operating Temperature (Max)	125 °C
Operating Temperature (Min)	-55 °C
Package / Case	Radial
Ratings	AEC-Q200
Size / Dimension Length	0.283 in
Size / Dimension Width	0.098 in
Termination	PC Pins
Tolerance	10 %
Voltage Rating - AC	63 V
Voltage Rating - DC	100 V
