CQB100W8-36S15N-C-B
ActiveCincon Electronics Co. LTD
ISOLATED DC/DC CONVERTERS - SMD 100W 9-75VIN 15VOUT 6.7A NEG MOUNT BUS
CQB100W8-36S15N-C-B
ActiveCincon Electronics Co. LTD
ISOLATED DC/DC CONVERTERS - SMD 100W 9-75VIN 15VOUT 6.7A NEG MOUNT BUS
Description
General part information
CQB100W8-36S15N-C-B
ISOLATED DC/DC CONVERTERS - SMD 100W 9-75VIN 15VOUT 6.7A NEG MOUNT BUS
Technical Specifications
Parameters and characteristics for this part
| Specification | CQB100W8-36S15N-C-B |
|---|---|
| Applications | Railway, ITE (Commercial) |
| Approval Agency | CE, cURus, CB, UKCA |
| Control Features | Enable, Active Low |
| Current - Output (Max) | 6.7 A |
| Efficiency | 90 % |
| Features | Remote Sense, Adjustable Output, Remote On/Off |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Quarter Brick |
| Package Name | Quarter Brick |
| Power (Watts) | 100 W |
| Size / Dimension Height | 0.5 in |
| Size / Dimension Length | 2.28 in |
| Size / Dimension Width | 1.45 in |
| Standard Number | 50155, 62368-1 |
| Type | Isolated Module |
| Voltage - Input (Max) | 75 V |
| Voltage - Input (Min) | 9 V |
| Voltage - Isolation | 4200 VDC |
| Voltage - Output 1 | 15 V |
