XDPA5050C4
ObsoleteSCHNEIDER ELECTRIC
MONOLEVER ROHS COMPLIANT: YES
XDPA5050C4
ObsoleteSCHNEIDER ELECTRIC
MONOLEVER ROHS COMPLIANT: YES
Description
General part information
XDPA5050C4
Joystick, 2 - Axis Output
Technical Specifications
Parameters and characteristics for this part
| Specification | XDPA5050C4 |
|---|---|
| Actuator Type | Joystick |
| Ingress Protection Description | Dust Tight, Water Resistant |
| Ingress Protection IP Rating | IP65 |
| Mechanical Life (Cycles) | 1000000 Cycles |
| Mounting Type | Panel Mount |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | -20 °C |
| Switch Function | 2-Way Directional |
| Termination Style | Screw Terminal |
| Type | Joystick, 2 - Axis |
