RNHT1206BTE32K4
ActiveStackpole Electronics Inc
RES AUTO, 32.4 KOHM, 1206, 0.1%,
RNHT1206BTE32K4
ActiveStackpole Electronics Inc
RES AUTO, 32.4 KOHM, 1206, 0.1%,
Description
General part information
RNHT1206BTE32K4
32.4 kOhms ±0.1% 0.25W, 1/4W Chip Resistor 1206 (3216 Metric) Anti-Sulfur, Automotive AEC-Q200 Thin Film
Technical Specifications
Parameters and characteristics for this part
| Specification | RNHT1206BTE32K4 |
|---|---|
| Composition | Thin Film |
| Features | Automotive AEC-Q200, Anti-Sulfur |
| Height - Seated (Max) | 0.026 in |
| Number of Terminations | 2 |
| Operating Temperature (Max) | 155 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 1206 (3216 Metric) |
| Package Name | 1206 |
| Power (Watts) | 250 mW |
| Power (Watts) Options | 1/4W |
| Ratings | AEC-Q200 |
| Resistance | 32.4 kOhm |
| Size / Dimension Length | 0.12 in |
| Size / Dimension Width | 0.061 in |
| Temperature Coefficient | 25 ppm/°C |
| Tolerance | 0.1 % |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
