MAL214097303E3
ActiveVishay Dale
SMD ALUMINIUM ELECTROLYTIC CAPACITOR, 140 CLH SERIES, 330 F, 6.3 V, RADIAL CAN - SMD, 8 MM ROHS COMPLIANT: YES
MAL214097303E3
ActiveVishay Dale
SMD ALUMINIUM ELECTROLYTIC CAPACITOR, 140 CLH SERIES, 330 F, 6.3 V, RADIAL CAN - SMD, 8 MM ROHS COMPLIANT: YES
Description
General part information
MAL214097303E3
330 µF 6.3 V Aluminum Electrolytic Capacitors Radial, Can - SMD 1500 Hrs @ 125°C
Technical Specifications
Parameters and characteristics for this part
| Specification | MAL214097303E3 |
|---|---|
| Applications | Automotive |
| Capacitance | 330 µF |
| Height - Seated (Max) | 0.413 in |
| Impedance | 400 mOhms |
| Lifetime | 1500 Hrs |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Radial, Can - SMD |
| Polarization | Polar |
| Ratings | AEC-Q200 |
| Ripple Current | 126 mA |
| Size / Dimension Diameter | 0.315 in |
| Surface Mount Land Length | 0.335 in |
| Surface Mount Land Width | 0.335 in |
| Tolerance | 20 % |
| Voltage - Rated | 6.3 V |
