G8SN-1C4P-DC12
ObsoleteOmron Electronics Inc-EMC Div
RELAY AUTOMOTIVE SPDT 10A 12V
G8SN-1C4P-DC12
ObsoleteOmron Electronics Inc-EMC Div
RELAY AUTOMOTIVE SPDT 10A 12V
Description
General part information
G8SN-1C4P-DC12
RELAY AUTOMOTIVE SPDT 10A 12V
Technical Specifications
Parameters and characteristics for this part
| Specification | G8SN-1C4P-DC12 |
|---|---|
| Coil Current | 66.7 mA |
| Coil Power | 800 mW |
| Coil Resistance | 180 Ohms |
| Coil Type | Non Latching |
| Coil Voltage | 12 VAC |
| Contact Form | C, 1, SPDT, Form |
| Contact Material | Silver Tin Oxide (AgSnO) |
| Contact Rating (Current) | 10 A |
| Mounting Type | Through Hole |
| Must Operate Voltage | 7.3 VDC |
| Must Release Voltage | 0.6 VAC |
| Operate Time | 10 ms |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Release Time | 10 ms |
| Switching Voltage DC (Max) | 16 VDC |
| Termination Style | PC Pin |
