AML21CBA3AC
ActiveHoneywell Sensing and Productivity Solutions
SWITCH PUSH BUTTON N.O./N.C. DPDT SQUARE BUTTON MOMENTARY THROUGH HOLE/PANEL MOUNT PC PINS/PUSH-ON
AML21CBA3AC
ActiveHoneywell Sensing and Productivity Solutions
SWITCH PUSH BUTTON N.O./N.C. DPDT SQUARE BUTTON MOMENTARY THROUGH HOLE/PANEL MOUNT PC PINS/PUSH-ON
Description
General part information
AML21CBA3AC
The AML21 series electronic control SPDT square Pushbutton Switch with standard bezel.
Technical Specifications
Parameters and characteristics for this part
| Specification | AML21CBA3AC |
|---|---|
| Actuator Marking | No Marking |
| Actuator Type | Button (Not Included), Square |
| Circuit | DPDT |
| Current Rating | 2 A, 3 A |
| Illumination Type | Incandescent |
| Mounting Type | Panel Mount, Snap-In |
| Panel Cutout Length | 19.05 mm |
| Panel Cutout Shape | Square |
| Panel Cutout Width | 19.05 mm |
| Switch Function | On-Mom |
| Termination Style | PC Pin |
| Type | Standard, Illuminated |
| Voltage Rating - AC | 125 V |
| Voltage Rating - DC | 24 V |
