Specification	VTF280SUF

Applications	Voltage Divider
Circuit Type	Voltage Divider
Height - Seated (Max)	0.28 in
Mounting Type	Through Hole
Number of Pins	3
Number of Resistors	2
Operating Temperature (Max)	70 °C
Operating Temperature (Min)	0 °C
Package / Case	3-SIP
Power Per Element	100 mW
Resistance	9 kOhm, 1 kOhm
Resistor Matching Ratio (Tolerance)	0.02 %
Resistor Ratio Drift	2 ppm/°C
Size / Dimension Length	0.32 in
Size / Dimension Width	0.1 in
Temperature Coefficient	10 ppm/°C
Tolerance	0.1 %
