Technical Specifications
Parameters and characteristics for this part
| Specification | CHV1206N250301GCT |
|---|---|
| Applications | SMPS Filtering |
| Capacitance | 300 pF |
| Features | High Voltage |
| Mounting Type | Surface Mount, MLCC |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 1206 (3216 Metric) |
| Size / Dimension Length | 0.126 in |
| Size / Dimension Width | 0.063 in |
| Temperature Coefficient | NP0, C0G |
| Thickness (Max) | 0.075 in |
| Tolerance | 2 % |
| Voltage - Rated | 250 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | Updated |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 4000 | $ 0.20 | <6d |
| 8000 | $ 0.20 | |||
| 12000 | $ 0.19 | |||
| 28000 | $ 0.19 | |||
| 100000 | $ 0.19 | |||
CAD
3D models and CAD resources for this part
Description
General part information
CHV1206N250301GCT
300 pF ±2% 250V Ceramic Capacitor C0G, NP0 1206 (3216 Metric)
