Description
General part information
26-07-200-0
CBLE CARRIER 1.97H X 2.95W 1=1FT
Technical Specifications
Parameters and characteristics for this part
| Specification | 26-07-200-0 |
|---|---|
| Cavity Height | 1.38 in |
| Cavity Width | 2.95 in |
| Frame Type | Open |
| Link Pitch | 2.2 in |
| Loading Side | Inside, Outside Bend |
| Material | Igumid G |
| Minimum Bend Radius | 7.87 in |
| Operating Temperature (Max) | 120 °C |
| Operating Temperature (Min) | -40 °C |
| Outer Height | 1.97 in |
| Outer Width | 3.58 in |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
