W 130 X - 2 X 4 OHM
ActiveVisaton GmbH & Co. KG
SPEAKER 8OHM 60W TOP PORT 78DB
W 130 X - 2 X 4 OHM
ActiveVisaton GmbH & Co. KG
SPEAKER 8OHM 60W TOP PORT 78DB
Description
General part information
W 130 X - 2 X 4 OHM
8 Ohms Subwoofer Speaker 60 W 40 Hz ~ 6 kHz Top Round
Technical Specifications
Parameters and characteristics for this part
| Specification | W 130 X - 2 X 4 OHM |
|---|---|
| Efficiency - dBA | 78 dBA |
| Efficiency - Testing | 1 W |
| Efficiency - Type | Sound Pressure Level (SPL) |
| Frequency - Self Resonant | 40 Hz |
| Frequency Range (Max) | 6 kHz |
| Frequency Range (Min) | 40 Hz |
| Height - Seated (Max) | 2.835 in |
| Impedance | 8 Ohm |
| Material - Cone | Polypropylene (PP) |
| Port Location | Top |
| Power - Max | 90 W |
| Power - Rated | 60 W |
| Shape | Round |
| Size / Dimension Diameter | 5.835 in |
| Technology | Magnetic |
| Termination | Quick Connect |
| Type | Subwoofer |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
