NV300-3LF
ActiveAstrodyne TDI
120W DC-DC 1/2 BRICK, 300V IN, 3
NV300-3LF
ActiveAstrodyne TDI
120W DC-DC 1/2 BRICK, 300V IN, 3
Description
General part information
NV300-3LF
Isolated Module DC DC Converter 1 Output 3.3V 25A 220V - 400V Input
Technical Specifications
Parameters and characteristics for this part
| Specification | NV300-3LF |
|---|---|
| Applications | ITE (Commercial) |
| Control Features | Active High, Enable |
| Current - Output (Max) | 25 A |
| Efficiency | 86 % |
| Features | Baseplate, Remote On/Off, Heat Sink |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 100 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Half Brick |
| Package Name | Half Brick |
| Power (Watts) | 83 W |
| Size / Dimension Height | 0.42 in |
| Size / Dimension Length | 2.4 in |
| Size / Dimension Width | 2.3 in |
| Standard Number | 60950-1 |
| Type | Isolated Module |
| Voltage - Input (Max) | 400 VDC |
| Voltage - Input (Min) | 220 V |
| Voltage - Isolation | 4.5 kV |
| Voltage - Output 1 | 3.3 V |
