89347
ActiveNTE Electronics, Inc
CAP CER 0.047UF 50V Y5V RADIAL
89347
ActiveNTE Electronics, Inc
CAP CER 0.047UF 50V Y5V RADIAL
Description
General part information
89347
0.047 µF -20%, +80% 50V Ceramic Capacitor Y5V (F) Radial, Disc
Technical Specifications
Parameters and characteristics for this part
| Specification | 89347 |
|---|---|
| Applications | General Purpose |
| Capacitance | 47 nF |
| Height - Seated (Max) | 0.532 in |
| Lead Spacing | 0.201 in |
| Lead Style | Straight |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -25 °C |
| Package / Case | Disc, Radial |
| Size / Dimension Diameter | 0.492 in |
| Temperature Coefficient | Y5V (F) |
| Tolerance (Negative) | 20 % |
| Tolerance (Positive) | 80 % |
| Voltage - Rated | 50 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
No documents available
