2906988
ActivePhoenix Contact
POWER RELAY, DPDT, 3A, 250A ROHS COMPLIANT: YES
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
2906988
ActivePhoenix Contact
POWER RELAY, DPDT, 3A, 250A ROHS COMPLIANT: YES
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | 2906988 | 29069 Series |
|---|---|---|
| - | - | |
| Approval Agency | cULus, EAC, UR | cULus, EAC, UR |
| Coil Current | 33 mA | 33 mA |
| Coil Resistance | 364 Ohms | 364 Ohms |
| Coil Type | Non Latching | Non Latching |
| Coil Voltage | 12 VDC | 12 VDC |
| Contact Form | DPDT (2 Form C) | DPDT (2 Form C) |
| Contact Material | Silver Tin Oxide (AgSnO) | Silver Tin Oxide (AgSnO) |
| Contact Rating (Current) | 8 A | 8 A |
| Mounting Type | Through Hole | Through Hole |
| Operate Time | 7 ms | 7 ms |
| Operating Temperature [Max] | 85 °C | 85 °C |
| Operating Temperature [Min] | -40 °C | -40 °C |
| Relay Type | General Purpose | General Purpose |
| Release Time | 3 ms | 3 ms |
| Switching Voltage | 250 VAC, 250 VDC | 250 VAC |
| Termination Style | PC Pin | PC Pin |
29069 Series
RELAY 120V
| Part | Contact Rating (Current) | Coil Resistance | Termination Style | Operating Temperature [Max] | Operating Temperature [Min] | Switching Voltage | Coil Type | Operate Time | Mounting Type | Coil Current | Coil Voltage | Contact Material | Contact Form | Approval Agency | Release Time | Relay Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Phoenix Contact 2906980 | ||||||||||||||||
Phoenix Contact 2906988 | 8 A | 364 Ohms | PC Pin | 85 °C | -40 °C | 250 VAC, 250 VDC | Non Latching | 7 ms | Through Hole | 33 mA | 12 VDC | Silver Tin Oxide (AgSnO) | DPDT (2 Form C) | cULus, EAC, UR | 3 ms | General Purpose |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
29069 Series
General Purpose Relay DPDT (2 Form C) 12VDC Coil Through Hole
