0261.202.016

Active

Flexa

ROHRFLEX PA6-L FLEXIBLE CONDUIT,

Search across all available documentation for this part.

Active

Flexa

ROHRFLEX PA6-L FLEXIBLE CONDUIT,

Technical Specifications

Parameters and characteristics for this part

Specification	0261.202.016

Color	Black
Diameter - Outside [diameter]	0.83 in
Diameter - Outside [diameter]	21.08 mm
Environment Protection	UV Resistant
Heat Protection	Flame Retardant
Length [x]	50 m
Length [x]	164 ft
Liquid Protection	Oil Resistant, Liquid-Tight, Fuel Resistant
Material	Halogen Free, Nylon 6, Polyamide (PA6)
Material Flammability Rating	UL94 HB
Operating Temperature [Max]	150 °C
Operating Temperature [Min]	-25 °C
Type	Protective Hose, Wire Loom
Type Attributes	Convoluted, Corrugated

ROHRFLEX PA6-L FLEXIBLE CONDUIT,

Part	Type Attributes	Color	Diameter - Outside [diameter]	Diameter - Outside [diameter]	Heat Protection	Material	Operating Temperature [Max]	Operating Temperature [Min]	Length [x]	Length [x]	Material Flammability Rating	Liquid Protection	Type	Environment Protection
Flexa 0261.202.016	Convoluted, Corrugated	Black	0.83 in	21.08 mm	Flame Retardant	Halogen Free, Nylon 6, Polyamide (PA6)	150 °C	-25 °C	50 m	164 ft	UL94 HB	Fuel Resistant, Liquid-Tight, Oil Resistant	Protective Hose, Wire Loom	UV Resistant

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1	$ 209.92

General part information

Black Polyamide (PA6), Nylon 6, Halogen Free Convoluted, Corrugated Wire Loom, Protective Hose 0.640" (16.26mm) 164' (50.00m)

Technical documentation and resources
