374723-E
ActiveTE Connectivity AMP Connectors
BOARD TO BOARD & MEZZANINE CONNECTORS 50-PIN,VERTICAL,SMT
374723-E
ActiveTE Connectivity AMP Connectors
BOARD TO BOARD & MEZZANINE CONNECTORS 50-PIN,VERTICAL,SMT
Description
General part information
- Series
PCB Mount Header, Vertical, Board-to-Board, 50 Position, 1 mm [.039 in] Centerline, Fully Shrouded, Gold (Au), Surface Mount, ERNI MicroSpeed
Technical Specifications
Parameters and characteristics for this part
| Specification | 374723-E |
|---|---|
| Connector Type | Array, Male Pins |
| Contact Finish | Gold |
| Features | Board Guide, Pick and Place, Ground Bus (Plane) |
| Height Above Board | 0.189 in |
| Mounting Type | Surface Mount |
| Number of Positions | 50 |
| Number of Rows | 2 |
| Pitch | 0.039 in |
